Size: 21.5"
Touch Think 21.5" display screen, 10mm front panel industrial monitor is designed to provide high quality picture and advanced features for reliable operation in harsh factory environment for many years.
Product Color
21.5" Industrial Monitor with High Brightness Touch Screen
Model: TPC215-M4
Touch Think HMI touch screen monitors provide high-definition images for the operator. With independent factory, R&D department, before and after-sales service team, cost-controlling department. Our industrial touchscreens monitors will be the most affordable brand for your project under high-quality conditions. These touchscreen monitors are ideal for industrial automation, engineering construction, and terminal equipment.
Product Features
● 7" to 21.5" available, according to different applications request
● High brightness screen available, 300nits ~ 1500nits option, sunlight-readable for outdoor use
● Supports wide temperature operation: -10° ~ +60°C
● Supports wide voltage operation: 12 ~ 36 Volt
● Auto-dimming function by the one-button switch.
● Multiple display input interfaces, including HDMI, DVI, and VGA
● Aluminum alloy housing, and fanless structure for heat-dissipation performance
● Offers reliable performance in heavy-duty applications due to good anti-vibration, anti-electromagnetic interference performance
Touch Think 21.5-inch Industrial Touch Screen Monitor
Industrial-Grade Touch Screen Monitor
Our 4th-GEN industrial monitors deliver the latest in LCD true flat panel technology, reliable Aluminum alloy casing for special purpose rugged industrial environments, such as industrial sites, Pharmaceutical, and food & beverage production lines areas.
The 21.5-inch monitor provides up to full high definition (FHD) 1920*1080 resolution with a LED backlight display and aspect ratios of 16:9.
IP65 Industrial Monitor
Our industrial monitors are built with front IP65-rating dustproof and waterproof protection, and endurance to wide temperature, strong shock, and vibration environments.
Industrial HDMI Monitor
HDMI, DVI, VGA, RJ45, and DisplayPort inputs are available on all our industrial monitors. And support I/O expansion.
24/7 Long-time Operation Monitors
What we provided is much more than just a simple industrial monitor, we provide reliable and extremely rugged industrial monitors with a multitude of uses. Supports 24/7 long-time running, and plug-and-play.
Reliable Operation, Ready For Automation
Our industrial monitor adopts a reliable industrial-grade drive board, it is designed for almost every field of application and industry that satisfies the highest performance standards and operational requirements. Multiple interfaces and modules ensure the components are ready for high automation.
The components on boards are perfectly coordinated and suitable for standard systems or customized applications to meet your needs.
Product Model Quick Guide
| Product Model | LCD Display | Resolution | Aspect Ratio | Touch Screen Type | Get A Quote Now! |
| TPC070-M-QD | 7" | 1024*600 | 16:9 | Capacitive / Resistive / Non-Touch | Inquiry |
| TPC080-M-QD | 8" | 1024*768 | 4:3 | Capacitive / Resistive / Non-Touch | Inquiry |
| TPC101-M4 | 10.1" | 1280*800 | 16:10 | Capacitive / Resistive / Non-Touch | Inquiry |
| TPC104-M4 | 10.4" | 1024*768 | 4:3 | Capacitive / Resistive / Non-Touch | Inquiry |
| TPC116-M4 | 11.6" | 1920*1080 | 16:9 | Capacitive / Resistive / Non-Touch | Inquiry |
| TPC120-M4 | 12" | 1024*768 | 4:3 | Capacitive / Resistive / Non-Touch | Inquiry |
| TPC150-M4 | 15" | 1024*768 | 4:3 | Capacitive / Resistive / Non-Touch | Inquiry |
| TPC156-M4 | 15.6" | 1920*1080 | 16:9 | Capacitive / Resistive / Non-Touch | Inquiry |
| TPC170-M4 | 17" | 1280*1024 | 5:4 | Capacitive / Resistive / Non-Touch | Inquiry |
| TPC173-M4 | 17.3" | 1920*1080 | 16:9 | Capacitive / Resistive / Non-Touch | Inquiry |
| TPC190-M4 | 19" | 1280*1024 | 5:4 | Capacitive / Resistive / Non-Touch | Inquiry |
| TPC191-M4 | 19.1" | 1440*900 | 16:10 | Capacitive / Resistive / Non-Touch | Inquiry |
| TPC21.5-M4 | 21.5" | 1920*1080 | 16:9 | Capacitive / Resistive / Non-Touch | Inquiry |
| Screen parameters | Screen size | 21.5 inch |
| Model | TPC215-M4 | |
| Resolution | 1920*1080 | |
| Proportion | 16:9 widescreen | |
| Gray-scale response time | 5ms | |
| Panel Type Industrial | Control A style TFT | |
| Point distance | 0.264mm | |
| Contrast | 1000 : 1 | |
| Backlight type | LED, use length≥50000h | |
| Display color | 16.7M | |
| Visual angle | 85/85/85/85 (L/R/U/D); (178° full view angle Customizable) | |
| Brightness | 350cd/m2 (higher brightness customizable) | |
| Touch-type | Resistive / capacitive / non-touchscreen | |
| Number of touches | ≥ 50 million times | |
| Other parameters | Power Supply | 4A External Power Adapter |
| Power Performance | 100-240V, 50-60HZ | |
| Input voltage | 12-24V | |
| Anti-static | Contact 4KV-air 8KV (can be customized ≥16KV) | |
| Power | ≤20W | |
| Anti-vibration | GB2423 standard | |
| Anti-interference | EMC|EMI anti-electromagnetic interference | |
| Dustproof and waterproof | Front panel IP65 dustproof and waterproof | |
| Housing Material | Black/Silver, Aluminum Alloy | |
| Installation method | Embedded, desktop, wall-mounted, VESA, panel mount | |
| Ambient temperature | <80%, non-condensable | |
| Working temperature | -10°C～60°C (customizable -30°C～80°C) | |
| Language menu | Chinese, English, German, French, Korean, Spanish, Italian, Russian | |
| O/I interface parameters | Signal Interface | DVI, HDMI, VGA |
| Power connector | DC with ring attachment (optional DC terminal block) | |
| Touch interface | USB | |
| Other interfaces | Audio input and output |
Touch Think 21.5 inch LCD touch screen monitors are suitable for the following applications
Industrial process control, Building automation, Advertising all-in-one machine, Medical & healthcare solutions, Mobile computing,
Embedded system, Smart energy management, Touch kiosks solution
