11.6 inch Industrial All-in-one Android Panel PC for Production Line MES Terminal Attendance Machine

Size: 11.6"

This 11.6" industrial-grade panel PC is specially engineered for the MES system, realizing accurate information transmission, and production tracking in a timely.

Product Color



11.6" Industrial Panel PC-Based MES Hardware Terminals


Model: TPC116-S300


Touch Think 11.6-inch industrial all-in-one panel PC engineered with ergonomic and solid, offers robust and reliable performance for digital production line MES terminal. It adopts to industrial-grade Android motherboard, meet the complex and harsh industrial environment. Support VESA, wall-hanging, and desktop mount. It is the best choice of MES terminals for data acquisition.


Product Features


● 11.6" display screen, 1920*1080 resolution

● HD LED industrial control screen

● Industrial-grade Android motherboard

● High compatibility, high/low-temperature resistance, anti-surge

● 2mm ultra-thin front bezel

● Robust Aluminum alloy housing

● IP65 seamless true flat panel

● Dustproof speaker holes

● 13.56MHz (read and write) NFC

● 100W HD 720P camera

● I/O ports expansion

● Support multiple functional modules, including NFC, RFID, scanner, camera, printer, etc.

● Exclusive equipment for MES manufacturing management system

● The installation method supports VESA, wall-mounted, embedded, desktop, etc.

  • product description
  • Product parameters
  • Application
  • OEM/ODM

11.6 Inch Industrial All-in-one PC for Production Line MES Terminal

10.1 Inch Touch PC Based MES Hardware Terminals

11.6 Inch Industrial All-in-one PC for Production Line MES Terminal



11.6 Inch Industrial All-in-one PC for Production Line MES Terminal


11.6 Inch Industrial All-in-one PC for Production Line MES Terminal



Screen Parameters
Screen Display11.6"
Resolution
1920*1080
Aspect Ratio16:9
Panel TypeIndustrial control A level screen with TFT
Viewing Angle85/85/85/85 (L/R/U/D)
Display Color16.7M
Brightness  300cd/m2
Interface ParametersDC port1*DC 2.1/industrial terminal
HDMISupport HDMI data output, maximum support 1080P
USB-OTG1
RJ45 Ethernet1*10M/100M/1000M adaptive Ethernet
SD/TFTF data storage, maximum support 64G
Phone Jack 3.5mm standard interface
SIM cardStandard SIM card interface supports various formats (depending on 3G/4G module)
RS2321*RS232(DB9)
RS485/RS422Optional
GPIO3-channel (industrial terminal)
LED warning lightOptional
Printer/Scan Code Gun/MicrophoneOptional (external connected)
Wide voltage input12V~36V Optional
Hardware ConfigurationCPU
RK3288-I, quad-core, 1.8GHz
Storage/hard diskEMMC 16G (16/32/64G optional, maximum support 64G)
RAMDDR3L default with 2G (4G optional)
ChipsetIntel Bay trail SOC chipset
Operating systemAndroid 7.1
Graphics cardMali-T764GPU dual-core, ultra-high performance GPU, supporting HDMI 4K output
WiFiDual-frequency 2.4/5G
Bluetooth / GPS / MICOptional
RTC (real-time clock) / Support
NFC13.56MHZ
Camera100W HD
LED indicatorRed/green/blue (combination)
Touch ScreenTouch screen typeProjected capacitive touch screen
Resolution500DPI
Input methodHandwriting or capacitive pen
Surface hardness7H
CalibrationSupport
Product ReliabilityOperating temperature-10 °C to +60 °C
Storage temperature-20 °C to +70 °C
Humidity95%, Non-Condensing
Power SupplyPower consumption (maximum)15W
Power consumption (standby)≤2W
Power inputAC 100-240V  50/60Hz
Power outputDC12V / 4A




10.1 Inch Touch PC-Based MES Hardware Terminals






We provide customization services including logo, appearance, color, installation methods, I/O ports, high brightness, viewing angle, touchscreen types, etc.

Please contact us for details.
