Size: 7" - 21.5"
As one of the leading industrial panel pc manufacturers, we supply multiple display size panel PCs with the desktop install. Including11.6-inch desktop industrial all-in-one tablet PC with a Windows system. Operate smoothly under multiple running web pages. Support customization service for other Windows versions.
Product Color
Industrial Grade Desktop All In One PC 11.6"
Touch Think standard industrial touchscreen PCs. All-in-one and rugged tablets are produced to perform perfectly and be stable under extreme industrial environments. Designed with the newest industrial aesthetic appearance, full of sense of technology and modernity. More durable and impact resistant. We can customize industrial-grade panel PCs for many applications and workstation conditions. In all, industrial-grade desktop computers adopt the latest electronic components and core parts to ensure the offer of high-lever performance tablets for customers.
Touch Think Industrial All In One Computer Features
• It adopts a J1900 industrial-grade quad-core processor, which supports running multiple web pages smoothly.
• Aluminum alloy materials structure and shell, more durable and better heating-dissipation, low power consumption.
• Compact-designed body, support running for a long time under harsh environments.
• We pay more attention to reliability, environmental adaptability, real-time performance,
• Interfaces support I/O expansion.
• Strong compatibility for OS. Widely used in industrial control, military, communications, electro power, network, AI, IoT, and other intelligent fields.
• TFT LCD display with LED backlight.
• Fanless design with Celeron® processor.
• Aluminum alloy enclosure and IP65-rated front bezel.
• Easy access to RAM design and storage.
• Supports desktop stand and panel mount, wall mount, VESA arm.
• Programmable OSD function key on the back panel.
Touch Think Industrial Windows Panel PC with Desktop Mount
Industrial Desktop Touch Screen Computer Windows System
Desktop Windows Panel PC with industrial quality and performance is suitably mounted in smart workshops, smart paperless conferences, smart classrooms, and retail, restaurant, as interactive operation consoles, realizing the touch control and data/image display functions.
For this desktop industrial panel PC series, we have 7" to 21.5" for options according to different applications.
J1900 Industrial Motherboard
Adopts industrial motherboard Intel J1900, quad-core CPU, frequency up to 2.4GHz. The page loads quickly and the application starts smoothly, suitable for 24/7 long time running in harsh environments.
Surface IP65-rating Dustproof and Waterproof
This desktop touch screen computer is IP65 compliant, CE and FCC certified, suitable in outdoor applications, and with fanless design, offers excellent heat-dissipation performance in harsh environments, including factory production lines, as well as manufacturing sites. Can be further customized to meet specific technical and industry needs.
Touch Screen or Non-Touch Screen Options
This tabletop touch screen computer supports 10-point projected capacitive screen and a 4/5-wire single-point resistive screen.
Due to this industrial panel PC is engineered with high flexibility and scalability. They can be used in a variety of applications, so also supports multi-touch screen technologies, capacitive, resistive, or mouse control. For being used for machine process control and motion sequence processes as well as data collection & acquisition, information display, and image processing.
Screen parameters | Screen size | 11.6 inch |
Model | TPC116-W4 | |
Resolution | 1920*1080 | |
Proportion | 16:9 widescreen | |
Motherboard parameters | CPU | intel Celeron J1900 2GHz quad-core (optional Intel Celeron 1037 1.8GHz dual core, optional Intel H81 equipped with Core i3/i5/i7) |
Hard Disk | 32G SSD (Optional 64G SSD/500G HDD) | |
Memory | 2G DDR3 (supports 8G DDR3) | |
Audio | Integrated Audio Chip | |
Network | Integrated Gigabit LAN | |
Wireless network | built-in wifi antenna, support wireless connection | |
Graphics Cards | Integrated Graphics | |
System | pre-installed windows7, support other | |
Speakers | available | |
Interface parameters | USB interface | 8"-10.4":USB2.0*2, Other sizes: USB2.0*3+USB3.0*1 |
Serial Interface | 8"-10.4": COM*1, Other Sizes: COM*2, Default RS232 Protocol, Can Change 422/485 Protocol | |
WIFI connector | WIFI antenna*1 | |
Power Interface | DC 12V*1 | |
High-definition interface | HDMI*1 | |
Extended display | VGA*1, support for synchronous dual display and differential display | |
Network interface | RJ-45*1 | |
Audio Interface | Audio I/O | |
Support extensions | Multiple industry interface support customization | |
Display parameters | Color | 16.7M |
Point distance | 0.264mm | |
Screen Panel | Industrial control panel | |
Contrast | 1000:1 | |
Display brightness | 400cd/m2 (customizable high brightness above 400cd/m2) | |
View angle | (H160 (V) 160, customizable wide viewing angle 178° | |
Backlight type | LED backlit screen Lifetime ≥ 50000h | |
Gray-scale response time | 5ms | |
Touch Optional | Resistive/Capacitive/Infrared Touch Screen | |
Installation method | Embedded, desktop, wall-mounted, cantilever | |
Other parameters | Power | 12V-5A Professional External Power Adapter |
Power consumption | ≤60W | |
Working temperature | -10°C~60°C | |
Storage temperature | -20°C~60°C | |
Relative humidity | 0%-65% (without condensation) | |
Material | Full body made of aluminum alloy material | |
Color | Silver or Black | |
Warranty Policy | One year warranty for free | |
Degree of protection | Front panel IP65 dust-proof and waterproof | |
Packing list | Industrial Tablet PC / Mounting Accessories / Power Cord / Power Adapter / Driver CD / Manual / Warranty Card |
Touch Think 11.6-inch industrial desktop PC with touch screen feature the latest in cutting-edge fanless chassis design. Engineered suitable for today's most challenging computing environments and mainly realize the touch control & display functions in the following applications:
• Operation Console In Smart Factory
• POS System
• Display Terminals In Production Line
• Display Terminals In Hospital
We provide OEM/ODM service for global customers, please feel free to contact us for details.
