10.1 inch Touch PC-Based MES Hardware Terminals With NFC RFID Card Reader Customized Logo

Size: 10.1"

This industrial panel PC-based terminal is specially designed for the factory's MES applications. And developed to meet the requirements of the harsh production environment.

Product Color

This industrial panel PC-based terminal is specially designed for the factory's MES applications. And developed to meet the requirements of the harsh production environment.

  • product description
  • Product parameters
  • Application
  • OEM/ODM


The panel PC-based terminal is specially designed for the factory's MES applications.

Developed to meet the requirements of the harsh production environment.


10.1 Inch Touch PC Based MES Hardware Terminals



10.1 Inch Touch PC Based MES Hardware Terminals

10.1 Inch Touch PC-Based MES Hardware Terminals


Provide Complete SDK Development Kit

It has built-in professional remote maintenance software, supports Android system customization, and provides system call interface API reference code.

10.1 Inch Touch PC Based MES Hardware Terminals

10.1 Inch Touch PC Based MES Hardware Terminals



10.1 Inch Touch PC-Based MES Hardware Terminals

10.1 Inch Touch PC Based MES Hardware Terminals

Screen Parameters
Screen Display10.1"
Resolution
1280*800
Aspect Ratio16:10
Panel TypeIndustrial control A level screen with TFT
Viewing Angle85/85/85/85 (L/R/U/D)
Display Color16.7M
Brightness  300cd/m2
Interface ParametersDC port1*DC 2.1/industrial terminal
HDMISupport HDMI data output, maximum support 1080P
USB-OTG1
RJ45 Ethernet1*10M/100M/1000M adaptive Ethernet
SD/TFTF data storage, maximum support 64G
Phone Jack 3.5mm standard interface
SIM cardStandard SIM card interface, supports various formats (depending on 3G/4G module)
RS2321*RS232(DB9)
RS485/RS422Optional
GPIO3-channel (industrial terminal)
LED warning lightOptional
Printer/Scan Code Gun/MicrophoneOptional (externally connected)
Wide voltage input12V~36V Optional
Hardware ConfigurationCPU
RK3288-I, quad-core, 1.8GHz
Storage/hard diskEMMC 16G (16/32/64G optional, maximum support 64G)
RAMDDR3L default with 2G (4G optional)
ChipsetIntel Bay trail SOC chipset
Operating systemAndroid 7.1
Graphics cardMali-T764GPU dual-core, ultra-high performance GPU, supporting HDMI 4K output
WiFiDual-frequency 2.4/5G
Bluetooth / GPS / MICOptional
RTC (real-time clock) / Support
NFC13.56MHZ
Camera100W HD
LED indicatorRed/green/blue (combination)
Touch ScreenTouch screen typeProjected capacitive touchscreen
Input methodHandwriting or capacitive pen
Surface hardness7H
CalibrationSupport
Product ReliabilityOperating temperature-10 °C to +60 °C
Storage temperature-20 °C to +70 °C
Humidity95%, Non-Condensing
Power SupplyPower consumption (maximum)15W
Power consumption (standby)≤2W
Power inputAC 100-240V  50/60Hz
Power outputDC12V / 4A




10.1 Inch Touch PC-Based MES Hardware Terminals







We provide customization services including logo, appearance, color, installation methods, I/O ports, high brightness, viewing angle, touchscreen types, etc.

Please contact us for details.
