High Resolution LCD Display For Medical Multi-parameter 12.1"

Size: 7" - 21.5"

This touch screen monitor used in medical equipment, built-with high-resolution color TFT LCD display, wide viewing angle, improves the working efficiency for staff.

Product Color




High-Resolution LCD Display For Medical Multi-Parameter


In the medicine field, observation or diagnose of disease needs some medical parameters. Then monitoring and recording these parameters is necessary. This action can be realized by using a medical monitor, the monitors transmit data from a monitor to a distant workstation to keep the hospital system running stable and normal.


Product Features


● Compliance with Android, Windows, Linux

● 7 inch to 21.5 inch available, LCD IPS panel

● 10-Point capacitive touch or single-point resistive touch

● Supports custom front camera, microphone

● Supports Ethernet with PoE

● 1*HDMI/VGA/DVI/DC port

● Serial Port (USB)

● VESA 75*75mm / 100*100mm




Product Model Quick Guide


Product Model

LCD Display

Resolution

Aspect Ratio

TPC070-M-YL

7"

1024*600

16:9

TPC080-M-YL

8"

1024*768

4:3

TPC101-M-YL

10.1"

1280*800

16:10

TPC104-M-YL

10.4"

1024*768

4:3

TPC116-M-YL

11.6"

1920*1080

16:9

TPC120-M-YL

12"

1024*768

4:3

TPC150-M-YL

15"

1024*768

4:3

TPC156-M-YL

15.6"

1920*1080

16:9

TPC170-M-YL

17"

1280*1024

5:4

TPC173-M-YL

17.3"

1920*1080

16:9

TPC190-M-YL

19"

1280*1024

5:4

TPC191-M-YL

19.1"

1440*900

16:10

TPC21.5-M-YL

21.5"

1920*1080

16:9


  • product description
  • Product parameters
  • Application
  • OEM/ODM

High Resolution LCD Display For Medical Multi-parameter 12.1"


This Touch Think medical touch screen monitor built with a military-grade Aluminum alloy structure,

features high and low-temperature resistance, corrosion resistance, and extrusion resistance.


It is engineered with fine workmanship and long service life, suitable for working in various complex medical environments.

The heat dissipation design of the whole monitor is simple and has no redundant internal wiring. And

 with high reliability, multi-environment adaptability, real-time, high scalability, EMC compatibility, etc. to ensure long-term stable work in the medical environment.


High Resolution LCD Display For Medical Multi-parameter 12.1"




Screen parametersScreen size7 inch to 21.5 inch
Gray-scale response time5ms
Panel Type IndustrialControl A style TFT
Point distance

0.264mm

Contrast1000:1
Backlight typeLED, use length≥50000h
Display color

16.7M

Visual angle160/160 (Customizable 178° full view angle)
Brightness 300cd/m2 (high brightness customizable)
Touch-typeResistive / capacitive / mouse control
Number of touches≥ 50 million times
Other parametersPower Supply4A External Power Adapter
Power Performance100-240V, 50-60HZ
Input voltage12-24V
Anti-staticContact 4KV-air 8KV (can be customized ≥16KV)
Power ≤48W
Anti-vibrationGB2423 standard
Anti-interferenceEMC | EMI anti-electromagnetic interference
Dustproof and waterproofFront panel IP65 dustproof and waterproof
Housing MaterialBlack/Silver, Aluminum Alloy
Installation methodEmbedded, desktop, wall-mounted, VESA, panel mount
Ambient humidity<80%, non-condensable
Working temperature-10°C~60°C (-30°C~+80°C is customizable)
Language menuChinese, English, German, French, Korean, Spanish, Italian, Russian
O/I interface parametersSignal Interface DVI, HDMI, VGA
Power connectorDC with ring attachment (optional DC terminal block)
Touch interfaceUSB
Other interfacesAudio input and output


Touch Think multi-size medical monitors suitable for medical equipment, including the following equipment.


Diagnostic Equipment

Diagnostic medical equipment is the equipment used in hospitals for the purpose of diagnosing a patient’s condition. Including medical imaging machines, such as X-ray machines, CT scan equipment, MRI scan, ultrasound, and echocardiography, etc.


Durable Medical Equipment (DME)

This type of medical equipment is used mainly for providing therapeutic benefits for certain conditions or illnesses. Can be used in the hospital or at home for patient care. Including automated wheelchairs, hospital beds, Traction equipment, patient lifts.


Treatment Equipment

Treatment equipment is the type of medical device that is designed to treat a specific condition.  Including infusion pumps, surgical machines, medical lasers, etc.


Life Support Equipment

Life support equipment is those medical devices intended to maintain the bodily function of a patient. Including Heart-lung Machines, Medical Ventilators, Dialysis machines, Incubators, etc.


Medical Laboratory Equipment

The medical laboratory equipment is often seen in diagnostic laboratories and medical clinics. They are intended for the analysis of genes, blood, urine, and other biological material. Including Blood gas analyzers, Drug testing analyzers, Hematology analyzers, Urinalysis analyzers, Coagulation analyzers, Microbiological systems, Electrolyte analyzers, Chemistry analyzers, etc.





Touch Think provides OEM/ODM customization service for global customers, please feel free to contact us and tell us your requirements.
