Size: 18.5"
The 18.5-inch Industrial Capacitive Touch Screen PC delivers reliable performance with a 1920x1080 FHD display, high-visibility panel, dual Wi-Fi, and rugged design for demanding industrial applications.
Product Color
Model: TPC185-A28
In modern industrial automation, reliability and performance are key to achieving smooth operations. The 18.5-inch Industrial Capacitive Touch Screen PC is designed to meet these needs, offering a 1920x1080 Full HD display, high-visibility panel, and dual Wi-Fi connectivity. Built for industrial environments, this rugged panel PC combines advanced touch technology with powerful computing to deliver exceptional performance in demanding applications.
18.5 Inch Full HD Display
The 1920x1080 FHD resolution provides sharp, clear visuals, ensuring operators can view data, graphics, and applications with precision. The high-visibility panel enhances readability even under bright lighting conditions, making it suitable for factories, control rooms, and outdoor kiosks.
Capacitive Touch Technology
Equipped with a responsive capacitive touch screen, the PC supports multi-touch operation, allowing for quick and intuitive interaction. This improves workflow efficiency and reduces input errors, especially in environments where speed and accuracy are essential.
Industrial-Grade Durability
Designed with robust housing and reliable components, this industrial touch screen PC withstands dust, vibration, and temperature variations. It is ideal for continuous operation in manufacturing plants, logistics facilities, transportation hubs, and other mission-critical industries.
Dual Wi-Fi Connectivity
The inclusion of dual Wi-Fi modules ensures stable, uninterrupted wireless communication. This feature is particularly valuable for remote monitoring, data transfer, and real-time connectivity in smart factories and IoT-based industrial systems.
Flexible Integration
With multiple I/O interfaces, wide voltage input options, and VESA/panel mounting support, the 18.5 inch industrial panel PC integrates seamlessly into automation systems, kiosks, and machine control stations.
The 18.5 inch Industrial Capacitive Touch Screen PC with 1920x1080 FHD display, high-visibility panel, and dual Wi-Fi connectivity is the perfect solution for industries seeking a balance of performance, durability, and connectivity. Whether used in automation, logistics, or energy management, this industrial panel PC provides a reliable platform for smarter, more efficient operations.
| Display Parameters | Model | TPC185-A28 | |
| Size | 18.5" | ||
| Resolution | 1920*1080 | ||
| Aspect Ratio | 16:9 | ||
| Contrast | 1000:1 | ||
| Display Color | 16.7M | ||
| Brightness | 270cd/㎡ (Optional high brightness) | ||
| Visual Angle | 89°/89°/89°/89° (L/R/U/D) | ||
| Backlight Type | LED backlight screen, service life ≥ 50000H | ||
| Touch Screen | Capacitive, Resistive, or Non-touch options | ||
| Motherboard Model Selection | CX3568-Z | CX3588-Z | |
| System Architecture | CPU | RK3568 Quad-Core 2.0GHz | RK3588 Octa-Core 2.4GHz |
| Core Architecture | Cortex-A55 | Quad-Core Cortex-A76 + Quad-Core Cortex-A55 | |
| GPU | ARM Mali-G52 MP2 | ARM Mali G610 MP4 | |
| Memory (DDR) | 2GB (4/8GB optional) | 8GB (16GB optional) | |
| Storage (eMMC) | 32GB (64/128/256GB optional) | 64GB (256GB optional) | |
| SATA | / | / | |
| Operating System | Android 12/14, Linux 5.10, Ubuntu 20.04/22.04, Debian 11 | Android 13.0, Linux 5.10, Ubuntu 20.04/22.04, Debian 11 | |
| Networking | Ethernet | 1*1000M (2*1000M Ethernet options) | 1*1000M Ethernet (1*1000M + 1*100 Mbit Ethernet options) |
| 4G | Optional. Based on the 4G module selection | Optional. Based on the 4G module selection | |
| WIFI | WIFI6, Dual-band 2.4/5GHz | WIFI6, Dual-band 2.4/5GHz | |
| Bluetooth | BT5.3 | BT5.3 | |
| Display Function | LVDS | Support 1920*1080 60Hz output | |
| EDP | Support 1920*1080 60Hz output | ||
| MIPI | Support 1920*1080 60Hz output | ||
| Mipi Camera | 30-pin FPC interface, supports 1300W Camera | ||
| HDMI Output | HDMI 2.0, support 4K 3840*2160 60Hz output | HDMI 2.1, support 8K 7680*4320 60Hz output | |
| HDMI Input | / | / | |
| Touch Function | Touch Interface | USB/IIC | USB/IIC |
| I/O Ports | MICRO USB | / | / |
| USB 2.0 | USB2.0*2 HOT(This can change to Gigabit Ethernet port), USB2.0*5 on board | USB2.0*2 HOT(This can change to Gigabit Ethernet port), USB2.0*3 on board | |
| USB 3.0 | USB3.0*2 (including OTG*1) | USB3.0*2（including OTG*1) | |
| RS232 | RS232*3 | RS232*3 | |
| RS485 | RS485*3 | RS485*3 | |
| TTL | TTL*2 | TTL*2 | |
| GPIO | GPIO*12 (input/output) | GPIO*6 (input/output) | |
| SIM Slot | Support | Support | |
| TF Slot | Support | Support | |
| CAN | CAN*1 | CAN*1 | |
| Speaker | 3.5mm standard Jack | 3.5mm standard Jack | |
| MIC | Support | Support | |
| Audio Port | 3.5mm earphone jack, supports input/output | 3.5mm earphone jack, supports input/output | |
| I/O Expansion | Available | Available | |
| Power | Power Input | DC 12~36V | DC 12~36V |
| Adapter | 24V / 2.5A | 24V / 2.5A | |
| Mechanical | Enclosure | Aluminum alloy housing | Aluminum alloy housing |
| Cooling System | Fanless | Fanless | |
| Mounting | Desktop, wall-mounted, VESA75/100mm, ceiling-mounted | ||
| Product Reliability | Working Temp | -10°C ~ 60°C | -10°C ~ 60°C |
| Storage Temp | -20°C ~ 70°C | -20°C ~ 70°C | |
| Ambient Humidity | 20% - 95% (relative humidity non-condensing) | 20% - 95% (relative humidity non-condensing) | |
| IP rating | Front IP65 | Front IP65 | |
The 18.5 inch industrial capacitive touch screen PC is widely used in:
● Industrial automation systems – HMI interfaces, machine control, and monitoring.
● Smart manufacturing – real-time production data visualization.
● Transportation and logistics – warehouse management, fleet monitoring.
● Energy sector – monitoring and control in power stations and distribution systems.
● Commercial kiosks – interactive displays and self-service terminals.
We support OEM/ODM customization service for global customers. Please feel free to contact us for details.
