Android Touchscreen Wall Tablet Panel PC for Industrial Control 12"

Size: 12

Touch Think industrial touch screen panel PC computers produced for HMI require affordable, faster, reliable performance and functionality of machine-level interface used in Machine-to-Machine (M2M), Internet of Things (IoT), Industrial Internet of Things (IIoT), building automation, HVAC control, access control, room reservation.

Product Color

  • 8”

  • 10.1”

  • 10.4”

  • 11.6”

  • 12”

  • 15”

  • 15.6”

  • 17”

  • 17.3”

  • 19”

  • 19.1”

  • 21.5”

8 inch android panel pc

10.1 inch android tablet pc

10.4 inch android panel pc

11.6 inch android tablet pc

12 inch android tablet pc

15 inch android tablet pc

15.6 inch android tablet pc

17 inch android tablet pc

17.3 inch android tablet pc

19 inch android tablet pc

19.1 inch android tablet pc

21.5 inch android tablet pc

  • product description
  • Product parameters
  • Application

Android Touchscreen Wall Tablet Panel PC for Industrial Control

Touch Think industrial Android panel PC, touch screen panel and comfort control panels for HMI, with

independent R&D and cost-control department, these industrial tablet PCs are low-cost, reliable and

stable performance, which applied to industrial automation control, PLC system, Internet of Things

(IoT), smart building automation, smart education, HVAC control, access control, check-in systems,

visitor authorization, room reservation, room scheduling, interactive security systems, interactive pa-

tient room information displays, as well as interactive scheduling systems in hotels, campus, govern-

ment and hospitals. And these Android all-in-one panel PCs support PoE technology features a sys-

tem that safely transfers electrical power, along with data, to remote devices over standard category

5 cable in an Ethernet network. It does not require modification of existing Ethernet cabling infrastruc-

ture, so deployment is simplified. The panel PC support kinds of customization service on terms of

functional modules, screen sizes, installation methods, etc.

Display of Touch Think Industrial Android All-in-one Panel PC

Rugged Android Industrial Tablets 12 inch

Touch Think All-in-one Android PC Features

1. The industrial Android panel PC is designed to full flat seamless front panel, easy to maintain, more

    suitable for embedded installation.

2. IP65 rated water-proof and dust-proof, effectively withstanding the infiltration of dust and water vapor.

3. Aluminum alloy shell is strong antioxidant, high hardness for the screen, 7H level, which enhanced

    protection performance for screen.

4. Shock-proof, high and low temperature resistance, working temperature range up to - 20 ~70°C.

5. The rear cover of panel PC designed with a circular arc structure, high heat-dissipation.

6. Anti-EMI: it meets EMI/EMC standard, performs perfect in harsh condition.

7. Reserved dustproof&waterproof horn hole: the horn adopts to technology of industrial sound transmision

    material, it also support dust-proof and waterproof.

8. External key adjustment function: built-in button for adjustment of screen brightness, it reduced complex

    and tedious operation.

9. Low power consumption due to advanced heating-dissipation features.

10. Low calorific value: The self-developed motherboard has very small calorific value, and the temperature

      of the motherboard is generally normal temperature, the industrial all-in-one PC support long-time stable

      running for the whole year.

11. Android industrial touch screen all-in-one boot-up time is short, generally only a few seconds.

12. Excellent performance in terms of video multimedia, data communication and other aspects.

13. Android industrial all-in-one tablet PC applied to complex environment, it support plug-and-play function.

     Industrial-grade motherboards are generally not affected by the environment, the lowest temperature can

     be - 20 degrees Celsius, the highest temperature can be about 70 degrees Celsius.

14. The Android all-in-one PC support multi-type of installation methods in different application.

Application of Touch Think Industrial Android Panel PC

Android Touchscreen Wall Tablet Poe Panel PC for Industrial Control 12"

Screen ParameterScreen Size12 inch
Type TPC120-A41
Aspect Ratio4:3 square screen
Motherboard ParameterCPUDefault with A64 Cortex-A53 Quad-Core 64 Bits 1.5GHz (RK3399 Cortex-A9 Quad-Core 1.6GHz, or RK3288 Cortex-A17 Quad-Core 1.8GHz optional )
Hard disk8G EMMC ( 4G/16G/32G/64G optional )
RAM 2GB DDR3 ( 4G/8G optional )
Operating SystemAndroid 6.0 ( Android 5.1/7.0 optional )
Decoding ResolutionSupport 1080P
Play ModeSupport timing, circulation, and broadcast mode
Network format3G, 4G, Ethernet, support wifi, Wireless peripherals
Picture formatSupport BMP、JPEG、PNG、GIF
RTCSupport(The mixed cell)
Ports ParameterUSB portUSB2.0(OTG)*1,USB2.0(HOST)*1
COM port8"-10.4":COM*1,other size:COM*2,Default RS232 protocols,can do 422/485 protocols
WIFI port WIFI antenna*1
Power port DC 12V*1
Card slot SIM card slot*1,TF card slot*1
Lan port RJ-45*1
Audio portAudio I/O
Support extendedMultiple industry interfaces support customization
LCD screen ParameterColor16.7M
Dot pitch 0.264mm
TFT  Industrial A standard screen  TFT panel
Luminance400cd/m2(High brightness can be customized above 400cd/m2)
Visual Angel(H160(V)160,Customizable WVA 178°
Backlight LED backlight life≥50000h
Response time5ms
Touch optionCapacitive/Mouse Control
Installation waysEmbedded、Desktop、Wall mount、Cantilever type
OthersPower adapter 12V-5A Professional external power adapter
Power Dissipation ≤24W
Operation Temperature-10℃~60℃
Storage Temperature-20℃~60℃
Relative Humidity 0%-65%(non-condensing)
MaterialFull aluminum alloy metal material
Warranty PolicyThe whole machine is guaranteed free for one year
IP gradeIP65 for the front bezel
Packing listIndustrial Android Panel PC/install fittings/Power Cable/Power Adapter/Driver CD/Instruction Book/Warranty Card

12 inch industrial Android tablet PCs are widely used in the following applications:

1. Industrial Automation: field services tablet, HMI panel PCs, CNC control, process control, manufacturing automation.

2. Medical Fields: hospital surgery room, bedside service device, nurse workstation, monitoring system.

3. Signage Systems: interactive control & displays, outdoor digital signage, POS system, Kiosk system.

4. Logistics & Transportation: data collection, data acquisition device, turnstile face recognition, access control.

We offer OEM/ODM service for global clients, please feel free to contact us for details.
