Best Industrial All in one Computer With Industrial Motherboard Wall Mount Panel PC

Size: 10.1" ~ 21.5"

Ultra-rugged design and IP65 water-proof / dust-proof industrial-grade protection for its front panel, ideal for working outside or in harsh environments. Withstand moisture and extreme temperatures.

Product Color

  • product description
  • Product parameters
  • Application
  • OEM/ODM

Industrial All-in-one Panel Computer Supports Wall-hanging Mount


Model: TPC-A4 Series



The Touch Think industrial all-in-one computers with Android OS are fully enclosed and ruggedized touch screen PCs with multi-control capacitive touchscreen, fanless, and a mute heat-dissipation design. These industrial tablet PCs can be used in a wide variety of applications thanks to their multiple installation methods, supporting open frames, wall mounts, desk stands, and swing arms, embedded into other cabinets. All Touch Think series of all-in-one computers utilize rugged industrial-grade motherboards & electronic components to enhance performance in harsh environments under all-weather conditions, such as heat, moisture, cold, and dust. Based on the demands of your applications, you can also choose our resistive touchscreen and non-touch screen.



Android Industrial Panel Computers Features


● Industrial aesthetic designed appearance, more elegant, black and silver colors are optional.

● The all-in-one tablet PC is pre-installed with Android 6.0 and supports Android 10.0 /11.

● We have an independent R&D department for designing and producing motherboards and drive boards.

● Provide SDK development kits for global customers and offer a more functional module service.

● The whole all-in-one PC adopts Aluminum alloy material for anti-oxidation and heat-dissipation performance.



Best All in one Computer Industrial Motherboard 17"


Functional Module Customization Service

Best All in one Computer Industrial Motherboard 17"





Display ParametersSize10.1"~21.5" Options
Backlight typeLED backlight screen, service life ≥ 50000H
Touch ScreenCapacitive, Resistive, or Non-touch options








Motherboard Model SelectionJWS64
JWS3288-IJWS3399-MAIN-LCX3399-ACX3568-ACX3588-A
System ArchitectureCPUA64 Quad-Core 1.5GHzRK3288 Quad-Core 1.8GHzRK3399 Six-Core 2.0GHzRK3399 Six-Core 2.0GHzRK3568 Quad-Core 2.0GHzRK3588 Octa-Core 2.1GHz
Core Architecture Cortex-A53Cortex-A17Dual-Core Cortex-A72 + Quad-Core Cortex-A53Dual-Core Cortex-A72 + Quad-Core Cortex-A53Cortex-A55Quad-Core Cortex-A76 + Quad-Core Cortex-A55
GPUMali-T764Mali-T764Mali-T860 MP4Mali-T860 MP4Mali-G52 2EEMali G610 MP4
Memory (DDR)2GB (8GB optional)2GB (4GB optional)4GB2/4GB2GB (4/8GB optional)4GB (8/32GB optional)
Storage (eMMC)16GB (32/64GB optional)16GB (32/64/128/256GB optional)32GB (64GB optional)32/64GB (256GB optional)32GB (64/128/256GB optional)64GB (128/256GB optional)
SATA////Support/
Operating SystemAndroid 6.0Android 7.1 / 10.0 / Linux4.4 / Ubuntu18.04 / Debian10.0

Android 7.1 / 9.0 / 11 / Ubuntu 18.04/

 Debian10.0 / Linux4.4

Android 7.1/9.0/11,

Linux 4.4 / Ubuntu 18.04 / Debian 10

Android 12 / Linux 5.10 / Ubuntu 20.04 / Debian 11Android 13.0








NetworkingEthernet1*10M/100M/1000M adaptive Ethernet

1*10M/100M/1000M adaptive Ethernet

1*10M/100M/1000M adaptive Ethernet

1*10M/100M/1000M adaptive Ethernet

1*10M/100M/1000M adaptive Ethernet1*Gigabit Ethernet + 1*100 Mbit Ethernet
4GOptional. Based on the 4G module selection
5G

/

/////
WIFI2.4GDual-band 2.4/5GDual-band 2.4/5GDual-band 2.4/5GWIFI6, 2.4GWIFI6, Dual-band 2.4/5G
BluetoothBT5.0BT5.0BT5.0BT5.0BT5.2BT5.0








Display FunctionLVDSSupport 1920*1080 60Hz output
EDP/1920*1080 60Hz output
MIPISupport 1920*1080 60Hz output
Mipi Camera30pin FPC interface, support 1300W Camera
HDMI OutputHDMI 2.0, support 4K 3840*2160 60Hz outputHDMI 2.1, support 8K 7680*4320 60Hz output
HDMI Input/HDMI Input, 24-pin FPC custom interface/HDMI Input, 24-pin FPC custom interface//
Touch FunctionTouch InterfaceUSB/IICUSBUSB/IIC
I/O PortsMICRO USB1*MICRO USB (OTG)/////
USB 2.0USB2.0*2 + USB2.0*4 on boardUSB2.0*2 (including OTG*1) + USB2.0*6 on boardUSB2.0*5 on boardUSB2.0*1 + USB2.0*5 on boardUSB2.0*4 on boardUSB2.0*1 + USB2.0*4 on board
USB 3.0//USB3.0*2 (including OTG*1)USB3.0*1(OTG)USB3.0*2 (including OTG*1)
USB3.0*1(OTG)
RS2323*RS232/TTL mutual conversion1*RS232, 2*TTL/RS232 optionalRS232*2RS232*2RS232*2RS232*2
RS485 / (Unless install RS232 to RS485 converter)RS485*1RS485*1RS485*1RS485*1
TTL3*RS232/TTL mutual conversion1*RS232, 2*TTL/RS232 optionalTTL*2TTL*2TTL*2TTL*2
GPIO3*GPIO output, 1*GPIO input, and 1*ADC portGPIO*7 (input/output)GPIO*8 (input/output)GPIO*8 (input/output)GPIO*12 (input/output)GPIO*6 (input/output)
SIM SlotSupportSupportSupportSupportSupportSupport
TF SlotSupportSupportSupportSupportSupportSupport
CAN////SupportSupport
Speaker3.5mm standard Jack
MICSupportSupportSupportSupportSupportSupport
Audio Port3.5mm earphone jack, support input/output
I/O Expansion Available








PowerPower Input12V DC12V DC12-36V DC12-36V DC12-36V DC12-36V DC
Adapter12V / 4A12V / 4A24V / 2.5A24V / 2.5A24V / 2.5A24V / 2.5A

MechanicalEnclosureAluminum alloy housing
Cooling SystemFanless
MountingPanel-mount, Embedded, desktop, wall-mounted, VESA75/100mm, open frame, etc.

Product

Reliability

Working Temp -20°C ~ 70°C
Storage Temp -30°C ~ 80°C
Ambient Humidity 5% - 95% (relative humidity non-condensing)
IP ratingFront IP65












Robust industrial Android panel PC


Perfect and Fanless Design - Wall-mounted Industrial Panel PCs


This panel PC is a standard operator panel that meets the requirements unique to specific industries. Especially in the industrial sites, factories, food manufacturing, warehouse, medical and packaging industries. These touch panel PCs are engineered to meet stringent requirements with respect to reliability and robustness. The QI department and special construction of Touch Think's products ensure that they do.
