17.3 Inch Android Industrial Waterproof Tablet PC RK3288 CE Approved

Size: 17.3

Industrial android tablets - robust effect on the go. It has classic desktop installation, also supports the VESA, embedded, wall-hanging, and open frame mount.

Product Color

  • product description
  • Product parameters
  • Application
  • OEM/ODM

17.3" Industrial Android Tablet PC With CE Approved

Model: TPC173-A2


Touch Think TPC173-A2 Series is an industrial-grade fanless panel PC that is available on Android 5.1/6.0/7.1/9.0/10.1 versions. This industrial touch screen computer runs on an ARM Cortex-A53 and also can operate Linux or Windows. It has a classic panel mount, and also supports the desktop, VESA, embedded, wall-hanging, and open frame mount.


17.3 Inch Android Industrial Waterproof Tablet PC Key Advantages

Display:

Size: 17.3 inches.

Resolution: Full HD (1920x1080) or higher.

Brightness: High brightness for outdoor visibility (typically 400-1000 nits).

Touchscreen: Capacitive touch with multi-touch support, possibly with glove and wet touch modes.

Durability:

Waterproof: IP65 or higher rating for water and dust resistance.

Rugged Design: MIL-STD-810G certification for shock, vibration, and drop resistance.

Performance:

Processor: Powerful ARM or x86 processors.

RAM: Minimum 4GB, preferably 8GB or more for better performance.

Storage: At least 64GB, expandable via microSD.

Operating System:

Android: The latest version for better compatibility and security features.

Connectivity:

Wi-Fi: Dual-band Wi-Fi 5 or Wi-Fi 6.

Bluetooth: Version 4.2 or higher.

GPS: Integrated GPS for location-based services.

Cellular: Optional 4G LTE for mobile connectivity.

Ports: USB, HDMI, Ethernet, and possibly serial ports for industrial use.

Battery:

Capacity: High-capacity battery for extended usage, possibly with hot-swappable batteries.

Charging: Fast charging support, possibly with a docking station.

Additional Features:

Cameras: Front and rear cameras for documentation and video calls.

Sensors: Accelerometer, gyroscope, ambient light sensor, etc.

Mounting Options: VESA mount compatibility for easy installation in various environments.

Accessories: Stylus, rugged carrying case, shoulder strap, etc.


We specialize in providing display solutions and OEM ODM services. Please let us know your application requirements and we will have a professional team contact you.


17.3 Inch Industrial Tablets Features

1. LCD monitors of the tablets are built with an aluminum alloy shell

2. Operating temperatures: -20°C to +70°C

3. High-performance industrial-grade electronic components

4. Anti-interference, compliance with the EMC / EMI standard, suitable for complex signal environments

5. A wide variety of inputs such as USB, HDMI, VGA, RJ45, and other I/O expansion ports for optional

6. High-quality industrial touch screen with A, A+ level, fast response to any operation, no drift phenomenon

7. Easy to install and operate and designed to be well-performed in harsh environments

8. Offer kinds of customization services according to your requirements

9. High and low-temperature resistance, anti-vibration

10. RoHS, CE, FCC, 3C ISO approved for quality guarantee


17.3 Inch Android Industrial Tablet PCs' Main Board Details

1. Ensure excellent electromagnetic compatibility and anti-oxidation ability.

2. Adopt Maili400 MP2 Dual-core, high-performance GPU, support HDMI out in 4K.

3. Support API code, and customer’s APP development.

4. Adopt a well-known brand of DDR, FLASH, and other good-quality electronic components to ensure stable performance.

5. SMT machine with Japanese brand, strictly manufacturing processor to ensure the high quality and stable performance of industrial Android Panel PCs.

6. Plug and play, support different sizes, and all resolution LVDS panels.





Display ParametersSize17.3"
Resolution1920x1080
Screen Ratio16:9
Brightness400 nits (Optional high brightness)
Contrast Ratio600:1
Viewing Angle89/89/89/89 (L/R/U/D)
Backlight typeLED backlight screen, service life ≥ 50000H
Touch ScreenCapacitive, Resistive, or Non-touch options









Motherboard Model SelectionJWS64
JWS3288-IJWS3399-MAIN-LCX3399-ACX3568-ACX3588-ACX-3588-G
System ArchitectureCPUA64 Quad-Core 1.5GHzRK3288 Quad-Core 1.8GHzRK3399 Six-Core 2.0GHzRK3399 Six-Core 2.0GHzRK3568 Quad-Core 2.0GHzRK3588 Octa-Core 2.1GHzRK3588 Octa-Core 2.1GHz
Core Architecture Cortex-A53Cortex-A17Dual-Core Cortex-A72 + Quad-Core Cortex-A53Dual-Core Cortex-A72 + Quad-Core Cortex-A53Cortex-A55Quad-Core Cortex-A76 + Quad-Core Cortex-A55Quad-Core Cortex-A76 + Quad-Core Cortex-A55
GPUMali-T764Mali-T764Mali-T860 MP4Mali-T860 MP4Mali-G52 2EEMali G610 MP4Mali G610 MP4
Memory (DDR)2GB (8GB optional)2GB (4GB optional)4GB2/4GB2GB (4/8GB optional)4GB (8/32GB optional)8GB (16/32GB optional)
Storage (eMMC)16GB (32/64GB optional)16GB (32/64/128/256GB optional)32GB (64GB optional)32/64GB (256GB optional)32GB (64/128/256GB optional)64GB (128/256GB optional)64GB (128/256GB optional)
SATA////Support/1*SATA hard drive port
Operating SystemAndroid 6.0Android 7.1 / 10.0 / Linux4.4 / Ubuntu18.04 / Debian10.0

Android 7.1 / 9.0 / 11 / Ubuntu18.04 /

 Debian10.0 / Linux4.4

Android 7.1/9.0/11,

Linux 4.4 / Ubuntu 18.04 / Debian 10

Android 12 / Linux5.10 / Ubuntu 20.04 / Debian 11Android 13.0Android 12 / Linux 5.10 / Debian11 / Ubuntu 20.04









NetworkingEthernet1*10M/100M/1000M adaptive Ethernet

1*10M/100M/1000M adaptive Ethernet

1*10M/100M/1000M adaptive Ethernet

1*10M/100M/1000M adaptive Ethernet

1*10M/100M/1000M adaptive Ethernet1*Gigabit Ethernet + 1*100 Mbit Ethernet2*10M/100M/1000M adaptive Ethernet
4GOptional. Based on the 4G module selection
5G

/

/////Support M.2 5G module interface
WIFI2.4GDual-band 2.4/5GDual-band 2.4/5GDual-band 2.4/5GWIFI6, 2.4GWIFI6, Dual-band 2.4/5GWIFI5/WIFI6 (optional), dual-band 2.4/5G
BluetoothBT5.0BT5.0BT5.0BT5.0BT5.2BT5.0BT4.2 (WIFI 5) / BT5.0 (WIFI 6)









Display FunctionLVDSSupport 1920*1080 60Hz output
EDP/1920*1080 60Hz output4K 3840*2160 output
MIPISupport 1920*1080 60Hz output
Mipi Camera30pin FPC interface, support 1300W Camera
HDMI OutputHDMI 2.0, support 4K 3840*2160 60Hz outputHDMI 2.1, support 8K 7680*4320 60Hz output
HDMI Input/HDMI Input, 24-pin FPC custom interface/HDMI Input, 24-pin FPC custom interface//HDMI 2.0, support 4K 3840*2160 60Hz input
Touch FunctionTouch InterfaceUSB/IICUSBUSB/IIC
I/O PortsMICRO USB1*MICRO USB (OTG)/////
USB 2.0USB2.0*2 + USB2.0*4 on boardUSB2.0*2 (including OTG*1) + USB2.0*6 on boardUSB2.0*5 on boardUSB2.0*1 + USB2.0*5 on boardUSB2.0*4 on boardUSB2.0*1 + USB2.0*4 on boardUSB2.0*5 on board
USB 3.0//USB3.0*2 (including OTG*1)USB3.0*1(OTG)USB3.0*2 (including OTG*1)
USB3.0*1(OTG)
USB3.0*4 (including OTG*1)
RS2323*RS232/TTL mutual conversion1*RS232, 2*TTL/RS232 optionalRS232*2RS232*2RS232*2RS232*2RS232*1; RS232/TTL*2 (optional)
RS485 / (Unless install RS232 to RS485 converter)RS485*1RS485*1RS485*1RS485*1RS485*1
TTL3*RS232/TTL mutual conversion1*RS232, 2*TTL/RS232 optionalTTL*2TTL*2TTL*2TTL*2TTL*1; RS232/TTL*2 (optional)
GPIO3*GPIO output, 1*GPIO input, and 1*ADC portGPIO*7 (input/output)GPIO*8 (input/output)GPIO*8 (input/output)GPIO*12 (input/output)GPIO*6 (input/output)
SIM SlotSupportSupportSupportSupportSupportSupport
TF SlotSupportSupportSupportSupportSupportSupport
CAN////SupportSupport
Speaker3.5mm standard Jack
MICSupportSupportSupportSupportSupportSupport
Audio Port3.5mm earphone jack, support input/output
I/O Expansion Available









PowerPower Input12V DC12V DC12-36V DC12-36V DC12-36V DC12-36V DC12-36V DC
Adapter12V / 4A12V / 4A24V / 2.5A24V / 2.5A24V / 2.5A24V / 2.5A24V / 2.5A

MechanicalDimension459*291*62mm
EnclosureAluminum alloy housing
Cooling SystemFanless
MountingPanel-mount, Embedded, desktop, wall-mounted, VESA75/100mm, open frame, etc.

Product

Reliability

Working Temp -20°C ~ 70°C
Storage Temp -30°C ~ 80°C
Ambient Humidity 5% - 95% (relative humidity non-condensing)
IP ratingFront IP65


The industrial tablet PCs are suitable for universal use, such as healthcare devices, building automation, industrial automation, industry 4.0, IoT, commercial terminals, POS systems, fleet management, logistics, and warehouse management, etc.

If you need advice for your special application, do not hesitate to contact our technical sales or support. We will find the right solution together.

We support all kinds of customization services, please feel free to contact us for details.
