Outdoor High Brightness Industrial Monitors Auto-dimming IP65 Protection

Size: 7" - 21.5"

High-brightness industrial touchscreen monitors for outdoor use are specialized display solutions designed to deliver clear, vibrant visuals in bright outdoor environments.

Product Color

  • product description
  • Product parameters
  • Application
  • OEM/ODM

Outdoor High Brightness Industrial Monitors Auto-dimming IP65 Protection



High-brightness industrial monitors for outdoor use are specialized display solutions designed to deliver clear, vibrant visuals in bright outdoor environments. These monitors feature enhanced brightness levels and robust construction to withstand harsh weather conditions, making them ideal for outdoor applications such as digital signage, outdoor kiosks, transportation displays, and industrial monitoring systems.




Product Model Fast Guide




Model NameScreen SizeResolution Aspect Ratio
BrightnessGet A Quote
TPC070-M87"1024*60016:9800cd/㎡Inquiry Now
TPC101-M810.1"1280*800 / 800*128016:101000cd/㎡Inquiry Now
TPC104-M810.4"1024*7684:3800cd/㎡Inquiry Now
TPC116-M811.6"1920*108016:9
900cd/㎡Inquiry Now
TPC120-M812"1024*7684:31000cd/㎡Inquiry Now
TPC150-M815"1024*7684:31000cd/㎡Inquiry Now
TPC156-M815.6"1920*108016:91000cd/㎡Inquiry Now
TPC170-M817"1280*10245:41000cd/㎡Inquiry Now
TPC173-M817.3"1920*108016:91000cd/㎡Inquiry Now
TPC190-M819"1280*10245:41000cd/㎡Inquiry Now
TPC215-M821.5"1920*108016:9
1000cd/㎡Inquiry Now





Product Features


● High Brightness Levels: These monitors are engineered from industrial-grade quality, and equipped with high-brightness displays typically ranging from  800 nits to 1000 nits or more, significantly higher than standard indoor industrial monitors. The increased brightness ensures excellent visibility even in direct sunlight or high ambient light conditions, maintaining readability and legibility of content.



● Sunlight Readability Enhancements: To further improve visibility in bright outdoor environments, high-brightness industrial monitors may incorporate sunlight-readable technologies such as anti-glare coatings, optical bonding, and high-contrast displays. These enhancements reduce glare, reflections, and screen washout, enhancing the overall viewing experience.



● Rugged Construction: High-brightness industrial monitors are built with durable materials and rugged enclosures to withstand exposure to harsh weather elements, temperature fluctuations, moisture, dust, and vandalism. They feature robust designs that meet IP65 (Ingress Protection) ratings for water and dust resistance, ensuring long-term reliability in outdoor environments.



● Wide Operating Temperature Range: These high nits industrial monitors are designed to operate reliably within a wide temperature range, typically from -20°C to 70°C or higher, ensuring consistent performance in extreme weather conditions. They incorporate advanced thermal management techniques to dissipate heat effectively and maintain internal components within operational limits.



● All-Weather Shelters: When high-brightness industrial monitors are installed in outdoor environments, a weather-proof shelter should be installed to protect the monitor from environmental hazards. These shelters are ruggedized to prevent water ingress, dust infiltration, and damage from impacts or vandalism.



● Energy Efficiency: Despite their high brightness levels, these monitors are designed to be energy-efficient to minimize power consumption and operating costs. They may incorporate LED backlighting technology, low-power components, and intelligent power management features to optimize energy usage without compromising performance.



● Connectivity and Integration: High-brightness industrial monitors offer a range of connectivity options, including HDMI, DisplayPort, VGA, and RS-232, enabling seamless integration with various input sources and industrial systems. They may also support remote monitoring and management capabilities for convenient operation and maintenance.








CPURTD2513 and RTD2556 options

Interface ParameterTouch interfaceRJ45 port standard (defined as USB)
HDMISupport HDMI data input, maximum support 1080P
VGA1
DVI1
DC Port1*DC2.1, support 12V-36V wide voltage power supply
Earphone JackStandard 3.5mm port
Audio PortAudio I/O
I/O ExpansionSupport I/O customization for various industries

Screen ParametersViewing Angle160°/160, full viewing angle 178° can be customized.
Backlight TypeLED, lifetime ≥50000h
Grayscale Response Time5ms
Touch TechnologyCapacitive, resistive, and non-touch

Product ReliabilityWorking Temperature-20°C ~ 70°C
Storage Temperature-30°C ~ 80°C
Operating Humidity0% ~ 90% RH, non-condensing

Power ParametersPower Consumption≤35W
Power Input DC 12V~36V

Packaging SpecificationWarranty PolicyOne year warranty
Packaging ListIndustrial monitor, embedded buckles, VGA cable, power adapter, power cord, warranty card, instruction manual.
