Industrial Panel Computer Compatible i3/i5/i7 CPU With Windows, Ubuntu, CentOS, Debian and Redhat Full HD Multi-Touch Panel 7" to 23.8" Options

Size: 7" ~ 23.8"

The industrial panel computer with Intel® Core™ i3/i5/i7 processor options, support for Windows, Ubuntu, CentOS, Debian, and Red Hat, and Full HD multi-touch displays from 7″ to 23.8″ provides a versatile and future-ready solution for industrial computing. Ideal for modern industrial automation, edge computing, and smart manufacturing applications.

Product Color

Black Silvery

Inquiry Now Next Product

product description
Product parameters
Application
OEM/ODM

Industrial Panel Computer with Intel® Core™ i3/i5/i7 CPUs, Multi-OS Support, and Full HD Multi-Touch Panels (7″–23.8″)

As industrial automation, smart manufacturing, and edge computing continue to expand, the need for high-performance industrial panel computers with broad software compatibility has become increasingly important. The industrial panel computer compatible with Intel® Core™ i3, i5, and i7 processors, supporting Windows, Ubuntu, CentOS, Debian, and Red Hat, and featuring Full HD multi-touch displays from 7 inches to 23.8 inches, delivers a powerful and flexible computing platform for demanding industrial applications.

Product Model Fast Guide

Product Models	LCD Displays	Resolution	Aspect Ratio	Brightness	*Dimension (LWD)*	Get A Quote Now!
TPC070-W31	7"	1024*600	16:9	300cd/㎡	233.56154.5652mm	Inquiry
TPC080-W31	8"	1024*768	4:3	300cd/㎡	233.56174.5656mm	Inquiry
TPC101-W31	10.1"	1280*800	16:10/10:16	500cd/㎡	293.6193.356.53mm	Inquiry
TPC104-W31	10.4"	1024*768	4:3	400cd/㎡	28823160.5mm	Inquiry
TPC116-W31	11.6"	1920*1080	16:9	250~300cd/㎡	323.7218.557.5mm	Inquiry
TPC120-W31	12"	1024*768	4:3	500cd/㎡	31925763.5mm	Inquiry
TPC121-W31	12.1"	1280*800	16:10	350cd/㎡	330227.3462mm	Inquiry
TPC133-W31	13.3"	1920*1080	4:3	400cd/㎡	373.62245.1757mm	Inquiry
TPC150-W31	15"	1024*768	4:3	350cd/㎡	379.8130064mm	Inquiry
TPC156-W31	15.6"	1920*1080	16:9	300cd/㎡	42026960mm	Inquiry
TPC170-W31	17"	1280*1024	5:4	250~300cd/㎡	41434567mm	Inquiry
TPC173-W31	17.3"	1920*1080	16:9	400cd/㎡	45829162mm	Inquiry
TPC185-W31	18.5"	1920*1080	16:9	300cd/㎡	486.5307.469.5mm	Inquiry
TPC190-W31	19"	1280*1024	5:4	400cd/㎡	45138066.5mm	Inquiry
TPC191-W31	19.1"	1440*900	16:10	250~300cd/㎡	48633267.5mm	Inquiry
TPC215-W31	21.5"	1920*1080	16:9	250~300cd/㎡	55734564.5mm	Inquiry
TPC238-W31	23.8"	1920*1080	16:9	250~300cd/㎡	60637661mm	Inquiry

Note: High-brightness screen optional.

High-Performance Intel® Core™ i3/i5/i7 Processor Options

These industrial panel computers support a wide range of Intel® Core™ processors, allowing system designers to scale performance according to application requirements:

Intel® Core™ i3 for standard HMI and control applications

Intel® Core™ i5 for multitasking, visualization, and edge computing

Intel® Core™ i7 for data-intensive processing and advanced industrial workloads

This CPU flexibility ensures optimal performance while maintaining energy efficiency and long-term system stability.

Broad Operating System Compatibility for Industrial Software

One of the key strengths of this industrial panel computer is its broad operating system compatibility, enabling seamless integration into existing IT and OT environments. Supported systems include:

Windows for mainstream industrial applications and legacy software

Ubuntu for open-source and customized industrial development

CentOS for enterprise-grade industrial systems

Debian for stable and lightweight deployments

Red Hat for mission-critical industrial and enterprise environments

Multi-OS support reduces system migration costs and enhances deployment flexibility.

Full HD Multi-Touch Display for Professional Interaction

Equipped with Full HD resolution panels, these industrial panel PCs deliver clear, detailed visuals essential for modern industrial interfaces. The multi-touch screen supports intuitive operation and improved user experience, offering precise and responsive touch interaction, support for multi-touch gestures, clear visualization of complex data, and graphical HMIs.

Full HD displays improve productivity in control rooms, factory floors, and monitoring stations.


Display Parameters	Size	7"~23.8"
	Backlight type	LED backlight screen, service life ≥ 50000H
	Touch Screen	Capacitive, Resistive, or Non-touch options

System Architecture	CPU Options	Intel Celeron J1900 Quad-Core 2.0GHz	i3 4th-Gen 4005U i3 5th-Gen 5020U i3 6th-Gen 6100U i3 7th-Gen 7100U i3 8th-Gen 8145U i3 10th-Gen 10110 i3 12th-Gen 1215U	i5 4th-Gen 4200U i5 5th-Gen 5300U i5 6th-Gen 6200U i5 7th-Gen 7200U i5 8th-Gen 8265U i5 10th-Gen 10210U i5 12th-Gen 1235U	i7 4th-Gen 4770 i7 5th-Gen 5600U i7 6th-Gen 6500U i7 7th-Gen 7500U i7 8th-Gen 8565U i7 10th-Gen 10510U i7 12th-Gen 1255U
	Architecture	Intel Bay Trail	Intel Haswell	Intel Alder Lake	Intel Comet Lake
	GPU	Intel HD Graphics	Intel HD Graphics 4400	Intel UHD Graphics	Intel Iris Xe Graphics 96
	Memory	DDR3 8GB	8GB	DDR4 4/8/16/32GB	8GB
	Storage	16GB (optional: 32/64/128/256/512GB)	128GB SSD (Optional: 256/512GB; 1/2/4TB, etc. HDD)	64/128/256/512GB SSD (optional: 1T/2T HDD)	128GB
	SATA	1*SATA3.0	1*SATA3.0	1*SATA3.0	1*SATA3.0
	MSATA	1*MSATA	1*MSATA	/	1*MSATA
	M.2	/	/	1*M.2	1*M.2
	Operating System	Win 7/10	Win 7/10	Win 10/11	Win 10/11 Windows Server 2016/2019(10th-GEN CPU)
		Ubuntu14.04.6/16.04.7/18.04.5/18.04.6/20.04.1/20.04.3/20.04.4/22.04	Ubuntu 14.04/16.04/18.04/20.04/22.04	/	Ubuntu 20.04/22.04
		CentOS 7.4/7.8/7.9; Redhat 7.4; Debian 11.6	CentOS 7.4/7.6/7.7/7.8/7.9/8.4; Redhat 7.4/8.7; Debian 10.0/11.4/11.6/12.2	/	Debian 11.4/11.6/12.2

Networking	Ethernet	2*10M/100M/1000M adaptive Ethernet	2*10M/100M/1000M adaptive Ethernet	2*10/100/1000/2500 Mbps	11000M+12.5G
	4G	Support	Support	Support	Support
	WIFI	Dual-band 2.4/5GHz	Dual-band 2.4/5GHz
	Bluetooth	BT4.0 (Optional)	BT4.0 (Optional)	BT5.0 (Optional)	BT5.0 (Optional)

Display Function	LVDS	Support 1920*1080 60Hz output	Support 1920*1080 60Hz output	Support 1920*1080 60Hz output	Support 1920*1080 60Hz output
	EDP	Supports 3840*2160 60Hz output	Supports 4096*2160 60Hz output	Supports 4096*2304 120Hz output	Supports 4096*2304 120Hz output
	VGA	Support 1920*1080 60Hz output	Support 1920*1080 60Hz output	Support 1920*1080 60Hz output	/
	HDMI	Supports 3840*2160 30Hz output	Supports 4096*2160 30Hz output	Supports 4096*2160 @60Hz output	Supports 4096*2160 @60Hz output
Touch Function	Touch Interface	USB	USB	USB	USB
I/O Ports	USB 2.0	USB2.02 + USB2.04 on board	USB2.02 + USB2.04 on board	USB2.0*2	USB2.02+USB2.02 on board
	USB 3.0	/	USB3.0*2	USB3.02 + USB3.02 on board (converted by 2*Type-C)	USB3.02+USB3.02 on board
	RS232	6*RS232 (one of which is for RS232/RS422/RS485 mutual conversion)	6*RS232 (one of which is for RS232/RS422/RS485 mutual conversion)	6*RS232 (one of which is for RS232/RS422/RS485 mutual conversion)	6*RS232 (one of which is for RS232/RS422/RS485 mutual conversion)
	RS485	1*RS232/RS422/RS485 mutual conversion	1*RS232/RS422/RS485 mutual conversion	1*RS232/RS422/RS485 mutual conversion	6*RS485 (one of which is for RS232/RS422/RS485 mutual conversion)
	RS422	1*RS232/RS422/RS485 mutual conversion	1*RS232/RS422/RS485 mutual conversion	1*RS232/RS422/RS485 mutual conversion	RS422*1 (supports RS485/RS232/RS485 switching)
	SIM Slot	1SIM Slot + 1SIM Slot on board
	MIC	Support
	Audio Port	3.5mm earphone jack, supports input/output
	I/O Expansion	Support

Power	Power Input	12-36V DC	12-36V DC	12-36V DC	12-36V DC
Power	Adapter	24V / 2.5A	24V / 2.5A	24V / 4A	24V / 4A

Mechanical	Enclosure	Aluminum alloy housing
	Cooling System	Fanless
	Mounting	Panel Mount

Product Reliability	Working Temp	-10°C ~ 60°C
	Storage Temp	-20°C ~ 70°C
	Ambient Humidity	5% - 95% (relative humidity non-condensing)
	IP rating	Front IP65
