HD LCD Screen Industrial Monitor Factory Price 10.1 inch

Size: 10.1"

VESA mount, desktop, and wall-hanging installation are the first installation choices for this product, suitable for industrial high-end equipment applications. With IP65 waterproof & dustproof for the front panel, offers low power consumption, anti-interference. Wide working temperature range from -10°to +60°C. Supports 7*24 hours operation.

Product Color

  • product description
  • Product parameters
  • Application
  • OEM/ODM

HD LCD Screen Industrial Monitor Factory Price 10.1 Inch


Model: TPC101-M4


This industrial monitor with a touch screen is designed with a compact appearance and industrial-grade performance for different harsh environments, such as industrial control sites, military industry, communication, grid, Network, and other kinds of intelligent fields.


Product Features


1. Fourth generation industrial display of Touch Think, new streamlined design of its appearance in compliance with ergonomic.

2. True flat front panel up to IP65 dust-proof and waterproof protection level.

3. The whole monitor is designed with a fully closed and fanless heating-dissipation structure.

4. Low power consumption for 7*24 long time running; high integration for all components; good stability in harsh environments.

5. Self-developed display drive board with high standard quality insurance.

6. Diversified input and output interfaces.

7. Aluminum alloy housing, good seismic resistance, and impact resistance.

8. Application environment: indoor/outdoor applications.

9. Ways to install: desktop, wall-mounted, VESA, also provide open frame monitor.



10.1-inch Industrial Monitor

HD LCD Screen Industrial Monitor Factory Price 10.1"

HD LCD Screen Industrial Monitor Factory Price 10.1"

HD LCD Screen Industrial Monitor Factory Price 10.1"




10.1 inch Industrial Touchscreen Monitor
Display
Luminance300cd/m2 (400-1500cd/m2 can be customized)
DisplayA + high brightness LED backlight panel
Backlight lifetime≥ 50000h
Point distance0.264mm
Display color16.7M
Response time5ms
Viewing angle160°/160°,  full view 178° can be customized
Touch screenCapacitive touch screen / Resistive touch screen / Mouse control
Touch lifetimeCapacitive/IR touch  ≥50 million times ,Resistive touch screen  ≥35 million times
Power adapter
Power input12V-5A power adapter
Power supply100-240V, 50-60Hz
Max Power Dissipation≤35W
Environment

Working temperature :-10~60°C, wide temp -30°~80°C can be customized;

Working humidity: <80%

The I/O Interface
WIFI                       1
DC12V                        1
VGA                           1
HDMI                              1
USB      8-10.4inch: USB2.0*2; other inch: USB2.0*3+USB3.0*1
LAN                       1
Audio I/O                        1
COM       8-10.4inch: 1*RS232; other size: 2*RS232 (RS485/RS422 for optional)

Touch Think industrial touch screen monitors are used in the following fields:


1. Industrial automation: laser equipment, automatic spot welder, CNC, Industrial Robots, process control, machine vision, production line control in food & beverage processing, etc.

2. Environmental protection: water treatment, sewerage treatment system, energy management.

3. Intelligent transportation: expressway toll station system, access control system in metra/train/bus station.

4. Terminal display projects: vending machines, ATM equipment, self-help device in public areas.




We have professional R&D and designing departments to support any of your OEM and ODM items.
