Size: 15"
The 15 inch Industrial Touch Screen Panel PC with PCAP (Projected Capacitive) Touch technology delivers the durability and precision required for factory automation, process control, and smart industrial applications.
Product Color
Model: TPC150-A28
Modern manufacturing demands rugged, high-performance computing that can withstand harsh conditions while providing a smooth user interface. The 15 inch Industrial Touch Screen Panel PC with PCAP (Projected Capacitive) Touch technology delivers the durability and precision required for factory automation, process control, and smart industrial applications.
Rugged 15-Inch Display for Harsh Environments
Built for continuous 24/7 operation, this industrial panel PC features a 15 inch high-resolution touchscreen enclosed in an industrial-grade chassis. The screen is scratch-resistant, dustproof, and designed to handle temperature extremes, making it ideal for manufacturing plants, machine shops, and cleanrooms.
Advanced PCAP Touch Technology
The PCAP multi-touch interface provides high sensitivity and accuracy, enabling operators to use gloves or bare fingers while maintaining precise control. Unlike resistive touch, PCAP ensures a smooth, tablet-like experience—perfect for SCADA systems, HMI dashboards, and interactive production monitoring.
Flexible Industrial Connectivity
Equipped with rich I/O options such as USB, RS-232/422/485, and dual Gigabit Ethernet ports, this 15 inch industrial touch screen PC integrates seamlessly with PLC controllers, IoT sensors, and factory networks. Optional Wi-Fi and 4G modules support cloud data collection and remote monitoring, helping businesses move toward Industry 4.0.
Space-Saving Panel Mount Design
The slim, panel-mount chassis allows easy installation into control cabinets, kiosks, and machine fronts, creating a clean, flush appearance. Multiple mounting methods—panel, VESA, or desktop—provide flexibility for diverse industrial setups.
Energy-Efficient Performance
Powered by a low-power, high-performance processor, this industrial computer delivers reliable computing without excessive heat or energy consumption. It supports major operating systems, including Android, Linux, and Ubuntu , for maximum compatibility with existing factory software.
The 15 inch Industrial Touch Screen Panel PC with PCAP Touch is a powerful, reliable solution for industrial automation, machine control, and smart manufacturing environments. Its rugged design, multi-touch precision, and rich connectivity make it the ideal choice for companies seeking long-term performance and easy integration.
| Display Parameters | Model | TPC150-A28 | |
| Size | 15" | ||
| Resolution | 1024*768 | ||
| Aspect Ratio | 4:3 | ||
| Contrast | 1000:1 | ||
| Display Color | 16.7M | ||
| Brightness | 350cd/㎡ (Optional high brightness) | ||
| Visual Angle | 89°/89°/89°/89° (L/R/U/D) | ||
| Backlight Type | LED backlight screen, service life ≥ 50000H | ||
| Touch Screen | Capacitive, Resistive, or Non-touch options | ||
| Motherboard Model Selection | CX3568-Z | CX3588-Z | |
| System Architecture | CPU | RK3568 Quad-Core 2.0GHz | RK3588 Octa-Core 2.4GHz |
| Core Architecture | Cortex-A55 | Quad-Core Cortex-A76 + Quad-Core Cortex-A55 | |
| GPU | ARM Mali-G52 MP2 | ARM Mali G610 MP4 | |
| Memory (DDR) | 2GB (4/8GB optional) | 8GB (16GB optional) | |
| Storage (eMMC) | 32GB (64/128/256GB optional) | 64GB (256GB optional) | |
| SATA | / | / | |
| Operating System | Android 12/14, Linux 5.10, Ubuntu 20.04/22.04, Debian 11 | Android 13.0, Linux 5.10, Ubuntu 20.04/22.04, Debian 11 | |
| Networking | Ethernet | 1*1000M (2*1000M Ethernet options) | 1*1000M Ethernet (1*1000M + 1*100 Mbit Ethernet options) |
| 4G | Optional. Based on the 4G module selection | Optional. Based on the 4G module selection | |
| WIFI | WIFI6, Dual-band 2.4/5GHz | WIFI6, Dual-band 2.4/5GHz | |
| Bluetooth | BT5.3 | BT5.3 | |
| Display Function | LVDS | Support 1920*1080 60Hz output | |
| EDP | Support 1920*1080 60Hz output | ||
| MIPI | Support 1920*1080 60Hz output | ||
| Mipi Camera | 30-pin FPC interface, supports 1300W Camera | ||
| HDMI Output | HDMI 2.0, support 4K 3840*2160 60Hz output | HDMI 2.1, support 8K 7680*4320 60Hz output | |
| HDMI Input | / | / | |
| Touch Function | Touch Interface | USB/IIC | USB/IIC |
| I/O Ports | MICRO USB | / | / |
| USB 2.0 | USB2.0*2 HOT(This can change to Gigabit Ethernet port), USB2.0*5 on board | USB2.0*2 HOT(This can change to Gigabit Ethernet port), USB2.0*3 on board | |
| USB 3.0 | USB3.0*2 (including OTG*1) | USB3.0*2（including OTG*1) | |
| RS232 | RS232*3 | RS232*3 | |
| RS485 | RS485*3 | RS485*3 | |
| TTL | TTL*2 | TTL*2 | |
| GPIO | GPIO*12 (input/output) | GPIO*6 (input/output) | |
| SIM Slot | Support | Support | |
| TF Slot | Support | Support | |
| CAN | CAN*1 | CAN*1 | |
| Speaker | 3.5mm standard Jack | 3.5mm standard Jack | |
| MIC | Support | Support | |
| Audio Port | 3.5mm earphone jack, supports input/output | 3.5mm earphone jack, supports input/output | |
| I/O Expansion | Available | Available | |
| Power | Power Input | DC 12~36V | DC 12~36V |
| Adapter | 24V / 2.5A | 24V / 2.5A | |
| Mechanical | Enclosure | Aluminum alloy housing | Aluminum alloy housing |
| Cooling System | Fanless | Fanless | |
| Mounting | Desktop, wall-mounted, VESA75/100mm, ceiling-mounted | ||
| Product Reliability | Working Temp | -10°C ~ 60°C | -10°C ~ 60°C |
| Storage Temp | -20°C ~ 70°C | -20°C ~ 70°C | |
| Ambient Humidity | 20% - 95% (relative humidity non-condensing) | 20% - 95% (relative humidity non-condensing) | |
| IP rating | Front IP65 | Front IP65 | |
1. Factory Automation & Robotics – Real-time machine control and production data visualization.
2. Process Control – Stable HMI platform for SCADA and MES systems.
3. Medical & Cleanroom – Durable, easy-to-sanitize surface for healthcare or laboratory use.
4. Kiosks & Terminals – Rugged, always-on touchscreen for public and industrial self-service stations.
We support OEM/ODM customization service for global customers. Please feel free to contact us for details.
