Size: 11.6"
This 11.6-inch rugged, sunlight-readable panel PC combines high brightness visibility, IP65 protection, and powerful computing to meet the needs of industrial automation, outdoor monitoring, and mission-critical operations. Its compact size allows easy installation in tight spaces without compromising on performance.
Product Color
Model: TPC116-A28
Businesses that require rugged computing in challenging environments need hardware that delivers both durability and visibility. The 11.6-inch Industrial Panel PC with a high-brightness LCD and an IP65-rated dustproof, waterproof front panel is engineered for factory floors, outdoor kiosks, and industrial automation where reliability is critical.
High Brightness LCD for Sunlight Readability
The 11.6 inch high brightness display ensures crystal-clear visibility even in direct sunlight or high ambient light conditions. This makes it ideal for semi-outdoor environments, production monitoring, and public-facing kiosks, where a standard screen would struggle with glare.
Rugged IP65 Front Panel Protection
With an IP65 dustproof and waterproof front panel, this industrial panel PC resists dust, dirt, moisture, and water splashes. It’s designed to withstand harsh factory settings, food processing facilities, and outdoor installations, reducing maintenance downtime and extending product life.
Industrial-Grade Performance
Powered by a high-efficiency processor and industrial-grade components, the 11.6 inch panel PC provides reliable 24/7 operation. Fanless cooling ensures silent, low-maintenance performance, while wide voltage input and temperature tolerance make it suitable for demanding industrial applications.
Flexible Connectivity & Integration
Multiple rich I/O interfaces, including USB, RS-232/422/485, and dual Gigabit Ethernet, enable seamless integration with PLCs, sensors, barcode scanners, and IoT devices. Optional Wi-Fi or 4G LTE modules support remote monitoring and cloud-based industrial control systems.
| Display Parameters | Model | TPC116-A28 | |
| Size | 11.6" | ||
| Resolution | 1920*1080 | ||
| Aspect Ratio | 16:9 | ||
| Contrast | 1000:1 | ||
| Display Color | 16.7M | ||
| Brightness | 250~300cd/㎡ (Optional high brightness) | ||
| Visual Angle | 89°/89°/89°/89° (L/R/U/D) | ||
| Backlight Type | LED backlight screen, service life ≥ 50000H | ||
| Touch Screen | Capacitive, Resistive, or Non-touch options | ||
| Motherboard Model Selection | CX3568-Z | CX3588-Z | |
| System Architecture | CPU | RK3568 Quad-Core 2.0GHz | RK3588 Octa-Core 2.4GHz |
| Core Architecture | Cortex-A55 | Quad-Core Cortex-A76 + Quad-Core Cortex-A55 | |
| GPU | ARM Mali-G52 MP2 | ARM Mali G610 MP4 | |
| Memory (DDR) | 2GB (4/8GB optional) | 8GB (16GB optional) | |
| Storage (eMMC) | 32GB (64/128/256GB optional) | 64GB (256GB optional) | |
| SATA | / | / | |
| Operating System | Android 12/14, Linux 5.10, Ubuntu 20.04/22.04, Debian 11 | Android 13.0, Linux 5.10, Ubuntu 20.04/22.04, Debian 11 | |
| Networking | Ethernet | 1*1000M (2*1000M Ethernet options) | 1*1000M Ethernet (1*1000M + 1*100 Mbit Ethernet options) |
| 4G | Optional. Based on the 4G module selection | Optional. Based on the 4G module selection | |
| WIFI | WIFI6, Dual-band 2.4/5GHz | WIFI6, Dual-band 2.4/5GHz | |
| Bluetooth | BT5.3 | BT5.3 | |
| Display Function | LVDS | Support 1920*1080 60Hz output | |
| EDP | Support 1920*1080 60Hz output | ||
| MIPI | Support 1920*1080 60Hz output | ||
| Mipi Camera | 30-pin FPC interface, supports 1300W Camera | ||
| HDMI Output | HDMI 2.0, support 4K 3840*2160 60Hz output | HDMI 2.1, support 8K 7680*4320 60Hz output | |
| HDMI Input | / | / | |
| Touch Function | Touch Interface | USB/IIC | USB/IIC |
| I/O Ports | MICRO USB | / | / |
| USB 2.0 | USB2.0*2 HOT(This can change to Gigabit Ethernet port), USB2.0*5 on board | USB2.0*2 HOT(This can change to Gigabit Ethernet port), USB2.0*3 on board | |
| USB 3.0 | USB3.0*2 (including OTG*1) | USB3.0*2（including OTG*1) | |
| RS232 | RS232*3 | RS232*3 | |
| RS485 | RS485*3 | RS485*3 | |
| TTL | TTL*2 | TTL*2 | |
| GPIO | GPIO*12 (input/output) | GPIO*6 (input/output) | |
| SIM Slot | Support | Support | |
| TF Slot | Support | Support | |
| CAN | CAN*1 | CAN*1 | |
| Speaker | 3.5mm standard Jack | 3.5mm standard Jack | |
| MIC | Support | Support | |
| Audio Port | 3.5mm earphone jack, supports input/output | 3.5mm earphone jack, supports input/output | |
| I/O Expansion | Available | Available | |
| Power | Power Input | DC 12~36V | DC 12~36V |
| Adapter | 24V / 2.5A | 24V / 2.5A | |
| Mechanical | Enclosure | Aluminum alloy housing | Aluminum alloy housing |
| Cooling System | Fanless | Fanless | |
| Mounting | Desktop, wall-mounted, VESA75/100mm, ceiling-mounted | ||
| Product Reliability | Working Temp | -10°C ~ 60°C | -10°C ~ 60°C |
| Storage Temp | -20°C ~ 70°C | -20°C ~ 70°C | |
| Ambient Humidity | 20% - 95% (relative humidity non-condensing) | 20% - 95% (relative humidity non-condensing) | |
| IP rating | Front IP65 | Front IP65 | |
Key Applications
1. Factory Automation – Monitor and control production lines with real-time HMI feedback.
2. Outdoor Kiosks & Digital Signage – Sunlight-readable display for public or semi-outdoor areas.
3. Food & Beverage Processing – IP65-rated front panel withstands washdowns and dust.
4. Smart Warehousing & Logistics – Connect to sensors and WMS software for inventory tracking.
