Size: 19.1"
This 19.1 inch industrial panel PC combines outdoor-ready brightness, rugged construction, and flexible VESA mounting to meet the demands of mission-critical industrial and commercial projects. Whether you’re building an outdoor control station or a sunlight-readable kiosk, it delivers long-term reliability and exceptional visual clarity.
Product Color
Model: TPC191-A28
The 19.1 inch Industrial Touch Panel PC is engineered for outdoor and high-ambient-light environments where durability and visibility are critical. Featuring a high-brightness sunlight-readable display and a universal VESA mount, this rugged panel computer is ideal for factory automation, outdoor kiosks, transportation hubs, and smart city projects.
Sunlight-Readable High Brightness Display
The 19.1 inch LCD delivers exceptional brightness for clear viewing in direct sunlight. Wide viewing angles and anti-glare coating ensure operators can monitor data or interact with applications without eye strain, even in harsh outdoor lighting.
Rugged VESA-Mountable Design
A standard VESA mounting interface allows easy installation on walls, poles, kiosks, or control cabinets. This flexibility simplifies integration into industrial enclosures, digital signage, and outdoor monitoring systems, while the fanless aluminum housing resists dust, vibration, and temperature extremes.
Powerful Industrial Performance
Built with high-efficiency industrial components, the 19.1 inch panel PC provides reliable 24/7 operation. Wide voltage input and extended temperature tolerance guarantee stability for critical edge-computing tasks, from data collection to real-time control.
Rich Connectivity for Seamless Integration
Multiple I/O interfaces—including USB, RS-232/422/485, and dual Gigabit Ethernet—make it easy to connect to PLCs, sensors, cameras, and IoT networks. Optional Wi-Fi, Bluetooth, and 4G/5G modules enable cloud connectivity and remote management, supporting Industry 4.0 and smart city applications.
| Display Parameters | Model | TPC191-A28 | |
| Size | 19.1" | ||
| Resolution | 1440*900 | ||
| Aspect Ratio | 16:10 | ||
| Contrast | 1000:1 | ||
| Display Color | 16.7M | ||
| Brightness | 250~300cd/㎡ (Optional high brightness) | ||
| Visual Angle | 89°/89°/89°/89° (L/R/U/D) | ||
| Backlight Type | LED backlight screen, service life ≥ 50000H | ||
| Touch Screen | Capacitive, Resistive, or Non-touch options | ||
| Motherboard Model Selection | CX3568-Z | CX3588-Z | |
| System Architecture | CPU | RK3568 Quad-Core 2.0GHz | RK3588 Octa-Core 2.4GHz |
| Core Architecture | Cortex-A55 | Quad-Core Cortex-A76 + Quad-Core Cortex-A55 | |
| GPU | ARM Mali-G52 MP2 | ARM Mali G610 MP4 | |
| Memory (DDR) | 2GB (4/8GB optional) | 8GB (16GB optional) | |
| Storage (eMMC) | 32GB (64/128/256GB optional) | 64GB (256GB optional) | |
| SATA | / | / | |
| Operating System | Android 12/14, Linux 5.10, Ubuntu 20.04/22.04, Debian 11 | Android 13.0, Linux 5.10, Ubuntu 20.04/22.04, Debian 11 | |
| Networking | Ethernet | 1*1000M (2*1000M Ethernet options) | 1*1000M Ethernet (1*1000M + 1*100 Mbit Ethernet options) |
| 4G | Optional. Based on the 4G module selection | Optional. Based on the 4G module selection | |
| WIFI | WIFI6, Dual-band 2.4/5GHz | WIFI6, Dual-band 2.4/5GHz | |
| Bluetooth | BT5.3 | BT5.3 | |
| Display Function | LVDS | Support 1920*1080 60Hz output | |
| EDP | Support 1920*1080 60Hz output | ||
| MIPI | Support 1920*1080 60Hz output | ||
| Mipi Camera | 30-pin FPC interface, supports 1300W Camera | ||
| HDMI Output | HDMI 2.0, support 4K 3840*2160 60Hz output | HDMI 2.1, support 8K 7680*4320 60Hz output | |
| HDMI Input | / | / | |
| Touch Function | Touch Interface | USB/IIC | USB/IIC |
| I/O Ports | MICRO USB | / | / |
| USB 2.0 | USB2.0*2 HOT(This can change to Gigabit Ethernet port), USB2.0*5 on board | USB2.0*2 HOT(This can change to Gigabit Ethernet port), USB2.0*3 on board | |
| USB 3.0 | USB3.0*2 (including OTG*1) | USB3.0*2（including OTG*1) | |
| RS232 | RS232*3 | RS232*3 | |
| RS485 | RS485*3 | RS485*3 | |
| TTL | TTL*2 | TTL*2 | |
| GPIO | GPIO*12 (input/output) | GPIO*6 (input/output) | |
| SIM Slot | Support | Support | |
| TF Slot | Support | Support | |
| CAN | CAN*1 | CAN*1 | |
| Speaker | 3.5mm standard Jack | 3.5mm standard Jack | |
| MIC | Support | Support | |
| Audio Port | 3.5mm earphone jack, supports input/output | 3.5mm earphone jack, supports input/output | |
| I/O Expansion | Available | Available | |
| Power | Power Input | DC 12~36V | DC 12~36V |
| Adapter | 24V / 2.5A | 24V / 2.5A | |
| Mechanical | Enclosure | Aluminum alloy housing | Aluminum alloy housing |
| Cooling System | Fanless | Fanless | |
| Mounting | Desktop, wall-mounted, VESA75/100mm, ceiling-mounted | ||
| Product Reliability | Working Temp | -10°C ~ 60°C | -10°C ~ 60°C |
| Storage Temp | -20°C ~ 70°C | -20°C ~ 70°C | |
| Ambient Humidity | 20% - 95% (relative humidity non-condensing) | 20% - 95% (relative humidity non-condensing) | |
| IP rating | Front IP65 | Front IP65 | |
Key Outdoor & Industrial Applications
1. Outdoor Kiosks & Digital Signage – Sunlight-readable interface for public information and ticketing systems.
2. Transportation & Logistics – Reliable operation in depots, bus stations, and rail yards.
3. Smart City Monitoring – Rugged edge device for environmental sensors and security systems.
4. Factory Automation – High-brightness HMI for bright manufacturing floors or semi-outdoor workstations.
