E-mail: touchtec@sztouchtec.com
Size: 8"
The 8 inch Industrial Android Panel PC offers a compact, rugged, and high-performance solution for factory automation, smart kiosks, and IoT applications. Powered by the Rockchip RK3568 or RK3588 processor, it delivers reliable computing and smooth graphics performance.
Product Color
Model: TPC080-A28
The 8 inch Industrial Android Panel PC offers a compact, rugged, and high-performance solution for factory automation, smart kiosks, and IoT applications. Powered by the Rockchip RK3568 quad-core processor and Mali-G52 GPU, it delivers reliable computing and smooth graphics performance while running the latest Android operating system with full Google Play support.
High-Performance RK3568 Quad-Core CPU
The ARM-based RK3568 ensures fast multitasking, real-time data processing, and stable operation in 24/7 industrial environments. Its low power consumption makes it ideal for energy-efficient edge computing, HMI dashboards, and mobile automation systems.
Advanced Mali-G52 GPU for Superior Graphics
The integrated Mali-G52 GPU provides fluid 3D graphics and 4K video playback, enabling rich visual interfaces for interactive displays, digital signage, and machine-control panels.
Google Play Support for Flexible App Deployment
Preloaded with Android OS and Google Play certification, this panel PC allows you to download and update apps directly, enabling quick integration with custom software, IoT platforms, and industrial monitoring tools.
Rugged 8 Inch Multi-Touch Display
The 8 inch capacitive touchscreen offers high brightness and wide viewing angles, ensuring clear visibility in bright factory lighting or semi-outdoor installations. Its multi-touch capability supports pinch-zoom and swipe gestures, even with light gloves.
Industrial-Grade Construction
Designed for harsh industrial environments, the panel PC features a fanless aluminum housing, wide temperature tolerance, and resistance to dust and vibration, guaranteeing long-term reliability in production lines, warehouses, and retail kiosks.
Versatile Connectivity
Rich I/O interfaces—including USB, RS-232/422/485, and dual Gigabit Ethernet—simplify integration with PLCs, barcode scanners, sensors, and IoT devices. Optional Wi-Fi, Bluetooth, and 4G module support cloud-based control and remote monitoring.
| Display Parameters | Model | TPC080-A28 | |
| Size | 8" | ||
| Resolution | 1024*768 | ||
| Aspect Ratio | 4:3 | ||
| Contrast | 1000:1 | ||
| Display Color | 16.7M | ||
| Brightness | 250~300cd/㎡ (Optional high brightness) | ||
| Visual Angle | 89°/89°/89°/89° (L/R/U/D) | ||
| Backlight Type | LED backlight screen, service life ≥ 50000H | ||
| Touch Screen | Capacitive, Resistive, or Non-touch options | ||
| Motherboard Model Selection | CX3568-Z | CX3588-Z | |
| System Architecture | CPU | RK3568 Quad-Core 2.0GHz | RK3588 Octa-Core 2.4GHz |
| Core Architecture | Cortex-A55 | Quad-Core Cortex-A76 + Quad-Core Cortex-A55 | |
| GPU | ARM Mali-G52 MP2 | ARM Mali G610 MP4 | |
| Memory (DDR) | 2GB (4/8GB optional) | 8GB (16GB optional) | |
| Storage (eMMC) | 32GB (64/128/256GB optional) | 64GB (256GB optional) | |
| SATA | / | / | |
| Operating System | Android 12/14, Linux 5.10, Ubuntu 20.04/22.04, Debian 11 | Android 13.0, Linux 5.10, Ubuntu 20.04/22.04, Debian 11 | |
| Networking | Ethernet | 1*1000M (2*1000M Ethernet options) | 1*1000M Ethernet (1*1000M + 1*100 Mbit Ethernet options) |
| 4G | Optional. Based on the 4G module selection | Optional. Based on the 4G module selection | |
| WIFI | WIFI6, Dual-band 2.4/5GHz | WIFI6, Dual-band 2.4/5GHz | |
| Bluetooth | BT5.3 | BT5.3 | |
| Display Function | LVDS | Support 1920*1080 60Hz output | |
| EDP | Support 1920*1080 60Hz output | ||
| MIPI | Support 1920*1080 60Hz output | ||
| Mipi Camera | 30-pin FPC interface, supports 1300W Camera | ||
| HDMI Output | HDMI 2.0, support 4K 3840*2160 60Hz output | HDMI 2.1, support 8K 7680*4320 60Hz output | |
| HDMI Input | / | / | |
| Touch Function | Touch Interface | USB/IIC | USB/IIC |
| I/O Ports | MICRO USB | / | / |
| USB 2.0 | USB2.0*2 HOT(This can change to Gigabit Ethernet port), USB2.0*5 on board | USB2.0*2 HOT(This can change to Gigabit Ethernet port), USB2.0*3 on board | |
| USB 3.0 | USB3.0*2 (including OTG*1) | USB3.0*2（including OTG*1) | |
| RS232 | RS232*3 | RS232*3 | |
| RS485 | RS485*3 | RS485*3 | |
| TTL | TTL*2 | TTL*2 | |
| GPIO | GPIO*12 (input/output) | GPIO*6 (input/output) | |
| SIM Slot | Support | Support | |
| TF Slot | Support | Support | |
| CAN | CAN*1 | CAN*1 | |
| Speaker | 3.5mm standard Jack | 3.5mm standard Jack | |
| MIC | Support | Support | |
| Audio Port | 3.5mm earphone jack, supports input/output | 3.5mm earphone jack, supports input/output | |
| I/O Expansion | Available | Available | |
| Power | Power Input | DC 12~36V | DC 12~36V |
| Adapter | 24V / 2.5A | 24V / 2.5A | |
| Mechanical | Enclosure | Aluminum alloy housing | Aluminum alloy housing |
| Cooling System | Fanless | Fanless | |
| Mounting | Desktop, wall-mounted, VESA75/100mm, ceiling-mounted | ||
| Product Reliability | Working Temp | -10°C ~ 60°C | -10°C ~ 60°C |
| Storage Temp | -20°C ~ 70°C | -20°C ~ 70°C | |
| Ambient Humidity | 20% - 95% (relative humidity non-condensing) | 20% - 95% (relative humidity non-condensing) | |
| IP rating | Front IP65 | Front IP65 | |
Key Applications
1. Factory Automation & HMI – Real-time production monitoring and equipment control.
2. Smart Retail & Kiosks – Interactive touch displays with seamless Android apps.
3. Logistics & Warehousing – Mobile data terminals and inventory management.
4. Edge AI & IoT Gateways – Compact computing for smart city and industrial IoT projects.
